Advanced front air bags with seat belt-use, passenger-weight sensors

Front side-impact air bags and side-impact air curtains with rollover protection

3-point seat belts for all seating positions

Front seat belt pretensioners with force limiters

Anti-lock Brake System with Electronic Brake Force Distribution & Brake Assist

Dynamic Stability Control and Traction Control System

Hill Launch Assist

Mazda Cruise Control with Stop & Go

Side-impact door beams

Engine-immobilizer antitheft system

Tire Pressure Monitoring System (TPMS)

LATCH rear seat child safety seat anchors & upper tether anchors

Child safety rear door locks

2.0L Engine type SKYACTIV®-G 2.0L DOHC 16-valve 4-cylinder petrol engine with i-stop

Maximum power 115kW @ 6,000rpm/ Horsepower 154 hp @ 6,000 rpm

Torque 200Nm @ 4,000rpm/ Torque 137 lb-ft @ 4,000 rpm

Displacement (cc) 1998

Bore x stroke (mm) 83.5 x 91.2

Compression ratio 13.0 : 1 Fuel system Advanced Direct Injection

Recommended fuel Unleaded (91RON or higher) or E10

Fuel efficiency 7L/100Km

SKYACTIV-VEHICLE DYNAMICS

Fuel system Advanced Direct Injection

Recommended fuel Regular unleaded

Valvetrain Chain-driven dual overhead cams, 4-valves per cylinder with variable valve timing (VVT)

Ignition system Direct coil-on-plug electronic ignition with platinum-tipped spark plugs

Engine block Aluminum alloy

Cylinder head Aluminum alloy

Type Front-wheel drive (FWD)

Automatic transmission SKYACTIV®-Drive 6-Speed automatic transmission with manual-shift and Sport mode

GEAR RATIOS (:1) Automatic Transmission

1st 3.552

2nd 2.022

3rd 1.452

4th 1.000

5th 0.708

6th 0.599

Reverse 3.893

Final drive 4.624

Brakes 4-wheel disc, diagonal hydraulic

- Front 297-mm vented disc

- Rear 303-mm solid disc

- ABS 4-wheel, 4-channel with Electronic Brake Force Distribution (EBD) and Brake Assist

Steering type Power rack-and-pinion with variable assist

Power assist Electronic Power Assist Steering (EPAS)

Steering wheel turns, lock-to-lock 2.7

Turning circle diameter, curb-to-curb (m) 10.9

Suspension 4-wheel independent

- Front MacPherson strut with stabilizer bar

- Rear Multilink with stabilizer bar

Curb weight (kg) 1,580

Towing Capacity (kg) 907.1

Fuel capacity (liters) 56

Dual-zone automatic climate control with pollen filter

Rear air conditioning vents

Power windows with driver's one-touch down/up feature

Speefd sensitive power door locks with 2-stage unlocking

Mazda Keyless Entry and Start System

Auto-dimming rearview mirror

Push Button Start Electronic parking brake

Dual covered illuminated visor vanity mirrors

Tilt & telescopic steering column

Map lights, Dome light and Cargo area light

Rear window defogger with timer

Overhead console with sunglasses holder

Center console armrest with tray and covered storage bin

Rear seat center armrest with integrated cup holders

Front and rear door bottle holders/storage

Driver and Front passenger seatback pockets

5-passenger seating capacity

Adjustable driver's seat with lumbar support

40/20/40 split one-touch fold-down and reclining rear seatback

Adjustable front and rear headrests

Leather-wrapped steering wheel

Leather-wrapped gear selector

Carpet floor mats

7" full-color touch screen display

Bluetooth® hands-free phone and audio capability HD Radio™

Rearview Camera

MAZDA CONNECT™ Infotainment System

Infotainment system voice command

Multifunction Commander Control

Auxiliary audio input jack

USB Inputs, 2 front and 2 rear

Steering wheel-mounted audio, phone and cruise controls

Speedometer, tachometer and fuel gauge, black background with white lettering and silver surround

Ambient temperature & clock display

Multi-Information Display (MID) with Trip computer

LED Headlights with Auto-leveling
LED Daytime Running Lights
LED fog lights
LED Combination taillights
Adaptive Front-lighting System
High Beam Control
Auto on/off headlights
Power Rear Liftgate with programmable height adjustment
Rain-sensing variable-intermittent windshield wipers I
ntermittent rear wiper/washer
Body-colored heated power side mirrors with integrated turn signals
Rear privacy glass
Roof-mounted "shark fin" antenna
Body-colored rear roof spoiler
Dual exhaust outlets with bright finish

19” Aluminum Wheels

Temporary spare tire

Wheelbase (mm) 2,700

Length (mm) 4,550

Width (mm) 1,840

Height (mm) up to roof, without roof rails, 1,660

Minimum ground clearance - Unladen (mm) 193
